Patent No. 379828
Constant pursuit and consistent efforts to maximize removal of the fine bagacillo from raw juice has led to invention of unique “Hot Raw Juice Rotary Screen”.
Major quantity of fibre solids are removed from raw juice at mill house and balance task is accomplished in this Rotary Juice Screen, allows improved “juice clarification”.
The screened raw juice from mills is generally heated to 70-75 deg. C. prior to liming and
sulphitation. After heating of juice the natural advantage of increase in fibre particle size and
good reduction of viscosity was considered as key point to develop a new Rotary Juice
Screening technology for screening of hot raw juice using much lesser opening screen.
In a normal milling plant the feed juice temperature is below 35 – 40 deg. C. and hence the
Rotary screen assembly for screening of unscreened mixed juice will be of “open” feature,
i.e. top frame, feed and discharge end drums are open to atmosphere.
However, considering the temperature of hot raw juice at 70-75 deg.C, it is essential to
provide Rotary Screen with our unique feature of “totally enclosed” arrangement to avoid
heat losses and to prevent subsequent reduction in temperature of screened hot raw juice.
In order to prevent escaping of vapours, the Rotary Screen is being provided with totally closed bolted top cover and totally enclosed feed and discharge end drums.
In case of sulphitation process the hot raw juice from the SO2 absorption tower is delivered to the juice inlet pipe of rotary screen and screened hot raw juice outlet of the screen is delivered to juice sulphiter (Juice Reaction Vessel) by gravity.
In case of defecation (only liming) process the hot raw juice from primary heaters is delivered to the juice inlet pipe of rotary screen and screened hot raw juice outlet of the screen is delivered to juice defecator (Juice Reaction Vessel) by gravity.
The bagasse discharged from the screen is delivered to a receiving tank by gravity and is pumped to mills or mud tank in a slurry form.
Fibre content of juice was analyzed using ICUMSA method GS7-13 (1994) and following are the findings,
Screened Raw Juice From Mills : 1700 – 2000 PPM (≅1.7 to 2.0 g/l)
Screened Hot Raw Juice : Less than 500 PPM (≅ 0.5 g/l)
We have so far designed, manufactured, supplied and successfully commissioned 63 nos. Rotary Screens for hot raw juice screening.
Advantages
- Reduction in clear juice colour.
- Reduction of clear juice turbidity and improved transmittance.
- Additional bagasse for extra power generation, when slurry is recycled to mills.
- Lowest fibre in screened hot raw juice – less than 500 ppm (0.5 g/l).
- The beverage floc test – Always ‘Negative’ using ICUMSA GS2/3-40 method.
- Sediments – Using ICUMSA GS2/3/9-19, always much below the desired norms of 100 mg/kg as per specification given by beverage manufacturer.
- Reduced solid and colour loading on subsequent clarification process of mixed juice, filtrate, syrup and melt.
- Other advantages like no chocking of pumps, headers and PHE.
